Vivotek FD8335H User Manual

VIVOTEK
14 - User's Manual
Ceiling mount
1� Attach the supplied alignment sticker to the ceiling�
2� Using the circle marks on the sticker, drill at least 2 pilot holes symmetrically on each
side into the ceiling� Then hammer the four supplied plastic anchors into the holes�
3� Through three or four holes on the mounting plate, insert the supplied screws into the
corresponding holes and secure the mounting plate with a screwdriver�
4� Feed the cables through the triangular cutout A or side opening B� If you want to use hole
B, remove the side cover using a screwdriver� Secure the camera base to the mounting
plate with three supplied screws�
5� Remove the black cover�
1
A
B
5
2
3
4
Black Cover
