VIVOTEK
6 - User's Manual
Physical Description
Inner View
General I/O T
erminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input
/
output
devices.
The
pin
denitions
are
described
below
.
The
24V AC
can
be
used
as
an
alternate power source�
8
7
6
5
4
3
2
1
IR LEDs (18 units, effective up to
15m)
Lens
T
ilt Adjustment
Screw
Black Cover
Ethernet 10/100 RJ45
Socket
Audio/Video Out
(green)
Microphone In
(pink)
General I/O T
erminal
Block
Jumpers
Microphone
Video
Output
Internal
External
NTSC
60Hz
PA
L
50Hz
1
2
Micro SD/SDHC Card Slot
Reset Button
Focus Assist
Button
1
AC24V_2
2
AC24V_1
3
DI3+
4
DI2+
5
DI1+
6
DI-
7
DO-
8
DO+ (12V)
5
