VIVOTEK
User's Manual - 7
DI/DO Diagram
Please refer to the following illustration for the connection method�
12V
+12V
Digital output
PIN 8
Power+12V
PIN 7
Digital input
PIN 3
DI-: Common Ground
PIN 6
NOTE:
The maximum output load from pins #7 & 8 is 50mA.
6
