VIVOTEK
84 - User's Manual
■ PIR (Passive Infra Red motion detector)
When directed towards an anticipated area of interest, the PIR can be used to detect movements or
intrusion, especially for detecting moving objects in the dark. PIR can be more effecive than video
motion detection� Shown below is the effective range of the PIR detector (IP8133 and IP8133W only)�
■ System boot
This option triggers the Network Camera when the power to the Network Camera is disconnected�
■ Recording notify
This option allows the Network Camera to trigger when the recording disk is full or when recording
starts to rewrite older data�
Vertical
82 degree
Horizontal
100 degree
Range:
5 meters
16.404 ft.
