Vivotek ND8312 - Physical Description

VIVOTEK - Built with Reliability
10 - User's Manual
Physical Description
Front View
Rear View
1
2
1
2
3
4
5
6
7
1 LAN and PoE activity LED: Please refer to page 28 for LED denitions.
2 USB 2.0 port
1 Antenna connector 5 USB port
2 Power socket (DC12V, 3A) 6 WPS/Reset button
3 10/100Mbps uplink port 7 Antenna connector
4 HDMI
1
The difference between the ND8212W and ND8312 is the antenna. The ND8312 comes without
the antenna.
