VIVOTEK - Built with Reliability
User's Manual - 155
2. Click and drag cameras from the Camera list to empty cells on your layout. Repeat the
action until you placed all your cameras into the layout. You may also double-click on a
camera's thumbnail to ll it into the rst unoccupied view cell.
To begin the design of your layout,
3
1. Select a layout pattern by a single click. The options are: 1x1, 2x2, 3x3, 1+5, 1+3, 1P+6,
2P+3, 3V. Since ND8212W supports 4 channels, some of the view cells in the multi-cell
layouts will not be available.
Camera list
2
3. When you lled up the current layout, click the page switch button to continue on the
next layout page.
5. On completion, click Save to preserve your setting.
To Next Page
