Vivotek ND8322P User Manual

VIVOTEK - Built with Reliability
126 - User's Manual
5-1. System
The system general information window allows you to change the system host name, time zone,
system date and time, and set up a scheduled reboot of the system.
Note that if NTP time server conguration is preferred, all cameras recruited into the
conguration will automatically listen to the time server on the NVR. If you make changes to the
conguration in the System > General settings > System time page, cameras will also listen
to the changes. The precondition is that the system must have access to the Internet.
5-1-1. System - General
Pnotify - During the conguration process, conguration errors or information will be indicated
by a small pnotify message boxes on the lower right of the screen.

Vivotek ND8322P Specifications

General

Card reader integrated	-
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
HDD capacity	6144 GB
Maximum storage capacity	12288 TB
Number of HDDs installed	2
Total installed storage capacity	12288 GB
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	8 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	1 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
