Vivotek ND8322P User Manual

VIVOTEK - Built with Reliability
User's Manual - 169
5-6-2. Editing Alarms via Source, Action, and Schedule
1. Editing an existing instance -
1-1. To remove an existing alarm, select by a left-click, and then click on the Remove button.
1
2
1-2. To edit an existing alarm, select by a left-click, and then click on the Source, Action,
or Schedule button on the left function tree. The associated parameters will display
on different windows. You can then edit the previous conguration such as selecting a
different triggering source, reactive action, or time span on a schedule.
1
3
2
While in the editing window, the Create and Remove buttons are not available.

Vivotek ND8322P Specifications

General

Card reader integrated	-
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
HDD capacity	6144 GB
Maximum storage capacity	12288 TB
Number of HDDs installed	2
Total installed storage capacity	12288 GB
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	8 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	1 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
