150 - User's Manual
To create a storage volume:
1. Click on the Create... button. Also check that if all your disk drives are listed. If properly
installed, they should all be listed in the Storage - Volume window.
Selected
(#) numbered: Volume index.
Disk: Member(s) of this volume.
Cacacity: Total usable capacity size in Gigabytes.
Used: The used capacity in Gigabytes.
Status: The status display when processing volume conguration, deleting, and
formatting a volume.
Error: Conguration or hard drive errors. The volume is invalid, and may need to
be manually removed.
The legends used in the Volume list are described below:
You can click to select a volume and its current status will be displayed as shown below. The
information will include its physical position, capacity, used capacity, and free capacity.

Vivotek ND8322P Specifications

General

Card reader integrated	-
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
HDD capacity	6144 GB
Maximum storage capacity	12288 TB
Number of HDDs installed	2
Total installed storage capacity	12288 GB
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	8 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	1 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
