160 - User's Manual
2. The Create Alarm wizard window will prompt. You can manually enter a name for the current
setting. You can enter up to 16 numeric or alphabetic characters for the name, including
symbols such as [0-9][a-z][A-Z][_][ ]. You can also designate the interval between one alarm
and the next triggered alarm to avoid the situation that the alarms can be too frequently
triggered.
Below is a glimpse of alarm sources and alarm actions:
Sources Actions
DI ► Video recording ►video footage
DO Email ►Email snapshots
Motion detection Buzzer
Disk failure FTP ►snapshots
Disk full Camera preset points ►Pan-tilt-zoom actions
PIR Camera DO
Tampering
To create an alarm,
1. Click on the Create... button.

Vivotek ND8322P Specifications

General

Card reader integrated	-
USB 2.0 ports quantity	3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	1
HDD capacity	6144 GB
Maximum storage capacity	12288 TB
Number of HDDs installed	2
Total installed storage capacity	12288 GB
Power consumption (max)	120 W
Certification	CE, LVD, FCC, VCCI, C-Tick, UL
LED indicators	HDD, Power, Status, eSATA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Maximum resolution	2560 x 1920 pixels
Alarm input channels	8
Video input channels	8 channels
Alarm output channels	4
Video formats supported	H.264
Resolution at capture speed	1920x1080@120fps
Minimum RAM	1 GB

Weight and Dimensions

Depth	311 mm
Width	360 mm
Height	44 mm
Weight	2700 g
