VIVOTEK - Built with Reliability
User's Manual - 43
2-2-6. Right-click Commands
Left-click to select a camera. Right-click to display the selection menu.
1.
Camera information
: Click to display camera name, resolution, codec, or frame rate on the
view cell. The information will display on the upper left corner of a view cell.
2.
Disable live streaming
: Choose to display snapshots on the screen instead. The snapshots
are regularly replaced.
3.
Fit screen with ratio
: The NVR server automatically optimizes the display of camera view
cells. However, you can still select this option to display the camera's original aspect ratio: for
example, the original video feed can be 4:3. Without the t screen, every camera's image will
be expanded to ll the view cell.
4.
Show tool bar
: You can hide the tool bars by deselecting this option.
5.
Pin status bar
: If selected, the status bar will constantly display on screen.
6.
Log in/Log out
: Log in to enable system conguration.
A time tab is displayed at the lower center of the screen. You can move your cursor to the lower
center to display the time tab and the alarm panel.
For the 3D counting cameras, right-click on its view cell to display the counting rule option. You
can enable the display of counting lines, and the bounding boxes for detected objects. The
counting results are acquired through the VIVOCloud utility.
Note that the NVR supports the
connection of up to 4 counting cameras.
The VCA rule displays only on the 2x2
layout.
