Vivotek ND9425P User Manual

VIVOTEK - Built with Reliability
User's Manual - 153
Item Name Description
14 Page changer Cick to move to the other layout page when your live views are distributed over
many pages.
15 Full screen Enters the full screen with only the live views.
Each panel will be described in further discussions.
4-2-1. Device List Panel
The Device list displays the recruited cameras by the sequential numbering order you congured
in the System Settings utility.
If a user logged in using a credential of a limited access, he may only see cameras that he can
access instead of all of the cameras.
Camera Icon:
A mouse click on the camera name on the Device list brings forth the summary of IP address,
model name, recording setup, DI/DO information, and other control elements on the right pane.
Sorting type

Vivotek ND9425P Specifications

General

PTZ control	Yes
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Audio formats supported	G.711, G.726
Video formats supported	H.264, H.265
Operating system installed	Embedded LINUX
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
VGA (D-Sub) output ports	1
HDD size	3.5 \
RAID levels	0, 1
HDD capacity	0 GB
HDD interface	USB 3.2 Gen 1 (3.1 Gen 1)
Maximum storage capacity	16 TB
Number of HDDs installed	0
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	255 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	320.3 mm
Width	366 mm
Height	46 mm
Weight	2500 g
