User's Manual - 75
Media Settings
Click Add Media on Event Settings page to open the media settings page� In this page, you can specify
what kind of media to send when a trigger is activated. A total of 5 media settings can be congured.
Media name: Enter a descriptive name for the media setting�
Media Type
There are three choices of media types available: Snapshot, Video clip, and System log�
Select the item
to display the detailed congurations. You can congure either one or all of them.
Snapshot: Select to send snapshots when a trigger is activated�
■ Source: Select to take snapshots from stream 1 or stream 2.
■ Send
pre-event images
The Network Camera has a buffer area; it temporarily holds data up to a certain limit� Enter a number
to decide how many images to be captured before a trigger is activated� Up to 7 images can be
generated�
■ Send
post-event images
Enter a number to decide how many images to be captured after a trigger is activated� Up to 7 images
can be generated�
For example, if both the Send pre-event images and Send post-event images are set to 7, a total of 15
images are generated after a trigger is activated�
■ File Name Prex
Enter the text that will be put in front of the le name.
■ Add date and time sufx to the le name
Select this option to add date and time to the le name sufx.
For example:
Click Save to enable the settings, and then click Close to quit the page�
1 pic. 2 pic. 3 pic. 4 pic. 5 pic. 6 pic. 7 pic. 8 pic. 9 pic. 10 pic. 11 pic. 10 pic. 12 pic. 13 pic. 14 pic. 15 pic.
The moment the trigger
is activated.
Snapshot_20080104_100341
Date and time suffix
The format is: YYYYMMDD_HHMMSS
File name prefix
