M-Flow valve operation options
The following valve operation options are available (see also the type code of each instrument):
Standard-knob
Standard-knob with locking ring
Hex socket and locking nut (instead of standard-knob)
Digiturn with indication
(100 divisions, cw-closed valve only)
Digi-knob
(100 divisons, ccw-closed valve only)
basic valve right- or left-handed
thread made from brass or
stainless steel
stop ring 518-1552
manual knob
manual knob
headless screw M3x6 512-8204
headless screw M5x5
disc Ø10x6.4/0.5 518-1550
locking nut 518-1554
2 x headless screw M3x3 512-8201
2 x headless screw M3x4 512-8202
2 x headless screw M3x3 512-8201
2 x headless screw M4x10 512-8217
headless screw M3x6 512-8204
digiturn knob 633-1102
reducing bush 518-1575
collar ring 518-1563
cover ring 633-1104
stargrip to digiturn knob 633-1103
digivö knob 633-1101
digibase 518-1553
