C
V
-values high-precision control valves M-Flow
C
V
-values valves NS1.0 to NS6.5
C
V
-value 1 = 1 m
3
/h water at Δp of 1bar
0.0000001
0.000001
0.00001
0.0001
0.001
0.01
0.1
1
0 2 4 6 8 10 12 14 16
cv-values
spindle turns
NS-1.0
NS-1.5
NS-2.0
NS-2.5
NS-3.0
NS-4.0
NS-6.5
