Dimensions M-Flow
M-Flow 25 straight valve
M-Flow 25 corner valve
Fitting
Dimensions in mm
Thread depth
a
b
G 1/4“ female
12
55
7
G 1/8“ female
12
55
8
NPT 1/4“ female
16
63
9
G 1/4“ female for
compression fittings
17
65
12
Fitting
Dimensions in mm
Thread depth
a
G 1/4“ female
12
7
G 1/8“ female
12
8
NPT 1/4“ female
16
9
G 1/4“ female for
compression fittings
17
12
8xM4
depth 4mm
