Vogtlin V-Flow Series User Manual

V-Flow Line
Manual
Version
Page
V-Flow Line
vflow_E4_7
© Vögtlin Instruments AG
35
Type code M-Flow
Instrument type
M-Flow
F
L
M
Instrument size
25
A
35
B
V-Stack
C
Materials (body, seals)
Aluminium/brass, FKM
S
Stainless steel, FKM
E
Stainless steel, EPDM
T
Stainless steel, FFKM
W
Customer-specific / OEM
K
Setup
Straight valve**
S
Corner valve
E
Valve insert without body
O
V-Stack, 1 valve/outlet
B
V-Stack, 2 valves/outlets
C
V-Stack, 3 valves/outlets
D
V-Stack, 4 valves/outlets
F
V-Stack, 5 valves/outlets
G
V-Stack, 6 valves/outlets
H
V-Stack, 7 valves/outlets
I
V-Stack, 8 valves/outlets
J
V-Stack, 9 valves/outlets
M
V-Stack, 10 valves/outlets
N
V-Stack, 11 valves/outlets
P
V-Stack, 12 valves/outlets
Q
Customer-specific / OEM
K
Valve (rolling direction)
Valve cw-closed**
S
Valve ccw-closed
L
Customer-specific / OEM
K
Process connection (in- and oulet)
G 1/4“ female** (Type 25)
S
G 1/8“ female (Type 25)
B
G 1/4" female, compression fittings (Type 25)
C
NPT 1/4" female (Type 25)
D
G 1/2“ female (Type 35)
S
Inlet: G 1", Outlet: G 1/2" (Type V-Stack)
S
Customer-specific / OEM
K
Valve size
NS 1.0 (Type 25)
A
NS 1.5 (Type 25)
B
NS 2.0 (Type 25)
C
NS 2.5 (Type 25)
D
NS 3.0 (Type 25)
E
NS 4.0 (Type 35 / V-Stack)
F
NS 6.5 (Type 35 / V-Stack)
G
Customer-specific / OEM
K
