Voith BTS User Manual

BTS, non
-contacting thermal switch unit
Installation
Installation and Operating Manual / Version 10 / 3626-011500 en / Protection Class
0: public / 2017-12-15
22
Installation dimensions for switching element and initiator:
Outer wheel side
Turbo coupling type
Pitch circle diameter
Ø F [mm]
Distance
~ H [mm]
206 T
196 ± 1
111.5
206 DT
196 ± 1
151.5
274 T
268 ± 1
152
274 DT
268 ± 1
190
366 T
350 ± 1
193
422 T
396 ± 1
206
487 T
470 ± 1
228
562 T
548 ± 1
248
650 T
630 ± 1
289
750 T
729 ± 1
318
866 T
840 ± 1
356
866 DT
840 ± 1
600
1000 T
972 ± 1
369
1000 DT
972 ± 1
672
1150 T
1128 ± 1
458
1150 DT
1128 ± 1
783
1330 DT
1302 ± 1
912
Table 5
Please see the assembly plan of the turbo couplings for installation dimensions of deviating
arrangements.
