Voith BTS User Manual

Installation and Operating Manual / Version 10 / 3626-011500 en
/ Protection class 0: public / 2017-12-15
23
BTS, non-contacting thermal switch unit
Installation
Arrangement of switching element on the shell side (not for turbo coupling type
DT and/or T…S):
Fig. 5
Arrangement of switching element on the shell side (only for turbo coupling
type T…S):
Fig. 6
75
h
Ø f
0190
0300
4 ± 1
75
h
Ø f
0190
0300
4 ± 1
