63
Symbols in the LC display
Symbol Meaning
Alarm indicator: Measured values are within the limits
defined during configuration.
No high/low alarm is set.
Alarm indicator: Measured values are exceeding the
limits defined during configuration.
Recording has been stopped.
Recording in progress.
Recording has been paused.
P
Device is ready to record: Device is configured, and
recording not started yet. It will disappear once the data
logger records.
Battery symbol: Full battery capacity
Battery symbol: Sufficient battery capacity
Battery symbol: Low battery capacity, replace the battery
ºC Unit for temperature value
%RH
Unit for relative humidity value
(DL-210TH, DL-220THP only)
