8.Technical Specifications
59
oscilloscope only, and Probes attenuation set as 10X. Only if the oscilloscope
fulfills the following two conditions at first, these specification standards can be
reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5 ℃ , do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on
P13).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Performance Characteristics
Instruction
Bandwidth
150 MHz
Channel
4 channels
Acquisition
Mode
Normal, Peak detect, Averaging
Sample rate
(real time)
1 GS/s
Input
Input coupling
DC, AC , Ground
Input impedance
1 MΩ±2%, in parallel with 15 pF±5 pF
Input coupling
1X,10X,100X,1000X
Max. input voltage
400V (DC+AC, PK - PK)
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel(typical)
150ps
Bandwidth limit
20 MHz, full bandwidth
Horizontal
System
Sampling rate range
0.5 S/s
～
1 GS/s
Interpolation
(Sinx)/x
Max Record length
80K
Scanning speed (S/div)
2 ns/div – 1000 s/div,
step by 1 – 2 - 5
Sampling rate / relay
time accuracy
±100 ppm
Interval(△T) accuracy
(DC - 100MHz)
Single
：
±(1 interval time+100 ppm×reading+0.6 ns);
Average>16
：
±(1 interval time +100 ppm×reading+0.4 ns)
Vertical system
Vertical Resolution (A/D)
8 bits (4 channels simultaneously)
Sensitivity
5 mV/div～5 V/div
Displacement
±2 V (5 mV/div – 200 mV/div)
±50 V (500 mV/div – 5 V/div)
Analog bandwidth
100 MHz
Single bandwidth
Full bandwidth
Low Frequency
≥10 Hz (at input, AC coupling, -3 dB)
