4.Advanced User Guidebook
How to Save and Recall a Waveform
Push the Utility button, select Function in the right menu, select Save in the left
menu. By selecting Type in the right menu, you can save the waveforms,
configures or screen images.
When the Type is selected as Wave, the menu is shown as the following table:
Display the save function menu
Choose the saving type as wave.
Choose the waveform to be saved.
(Choose All to save all the waveforms
that are turned on. You can save into
the current internal object address, or
into USB storage as a single file.)
The object Wave0 –Wave15 are listed
in the left menu, turn the M knob to
choose the object which the waveform
is saved to or recall from.
Recall or close the waveform stored in
the current object address. When the
show is ON, if the current object
address has been used, the stored
waveform will be shown, the address
number and relevant information will be
displayed at the top left of the screen; if
the address is empty, it will prompt
"None is saved".
Close all the waveforms stored in the
object address.
For internal storage, only BIN can be
selected. For external storage, the
format can be BIN, TXT or CSV.
Save the waveform of the source to the
selected address.
Save to internal storage or USB
storage. When External is selected, the
file name is editable. The BIN
waveform file could be open by
waveform analysis software (on the
supplied CD).
