VOLTCRAFT DSO-2154 - General Technical Specifications

8.Technical Specifications
61
Performance Characteristics
Instruction
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger
slope
Rising, Falling
Video Trigger
Modulation
Support standard NTSC, PAL and
SECAM broadcast systems
Line number
range
1-525 (NTSC) and 1-625
(PAL/SECAM)
General Technical Specifications
Display
Display Type
7" Colored LCD (Liquid Crystal Display)
Display Resolution
800 (Horizontal) × 480 (Vertical) Pixels
Display Colors
65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical)
About 5 V, with the Peak-to-Peak voltage ≥1 MΩ.
Frequency (Typical)
Square wave of 1 KHz
Power
Mains Voltage
100 - 240 VACRMS, 50/60 Hz, CAT Ⅱ
Power Consumption
< 15 W
Fuse
2 A, T class, 250 V
Environment
Temperature
Working temperature: 0 ℃ - 40 ℃
Storage temperature: -20 ℃ - 60 ℃
Relative Humidity
≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method
Natural cooling
Mechanical Specifications
Dimension
301 mm× 152 mm×70 mm (L*H*W)
Weight
About 1.1 kg
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
