4.Advanced User Guidebook
When the Type is selected as Configure, the menu is shown as the following
table:
Display the save function menu
Choose the saving type as configure.
Save the current oscilloscope configure
to the internal storage
Recall the configure from the selected
address
When the Type is selected as Image, the menu is shown as the following table:
Display the save function menu
Choose the saving type as image.
Save the current display screen. The
file can be only stored in a USB
storage, so a USB storage must be
connected first. The file name is
editable. The file is stored in BMP
format.
Save and Recall the Waveform
The oscilloscope can store 16 waveforms, which can be displayed with the current
waveform at the same time. The stored waveform called out can not be adjusted.
In order to save the waveform of CH1, CH2, CH3, CH4 and Math into the object
Wave0, the operation steps should be followed:
1. Turn on CH1, CH2, CH3, CH4 and Math channels.
2. Push the Utility button, select Function in the right menu, select Save in the
left menu. In the right menu, select Type as Wave.
3. Saving: In the right menu, select Source as All.
4. In the right menu, press Object. Select Wave0 as object address in the left
menu.
5. In the right menu, press Next Page, and select Storage as Internal.
6. In the right menu, press Save to save the waveform.
7. Recalling: In the right menu, press Prev Page, and press Object, select
Wave0 in the left menu. In the right menu, select Object as ON, the waveform
