4.Advanced User Guidebook
stored in the address will be shown, the address number and relevant
information will be displayed at the top left of the screen.
In order to save the waveform of CH1, CH2, CH3, CH4 into the USB storage as a
BIN file, the operation steps should be followed:
1. Turn on CH1, CH2, CH3, CH4 channels, turn off the Math channel.
2. Push the Utility button, select Function in the right menu, select Save in the
left menu. In the right menu, select Type as Wave.
3. Saving: In the right menu, select Source as All.
4. In the right menu, press Next Page, and select File Format as BIN.
5. In the right menu, select Storage as External.
6. In the right menu, select Storage, an input keyboard used to edit the file name
will pop up. The default name is current system date and time. Turn the M
knob to choose the keys; press the M knob to input the chosen key. The length
of file name is up to 25 characters. Select the
key in the keyboard to
confirm.
7. Recalling: The BIN waveform file could be open by waveform analysis
software (on the supplied CD).
Shortcut for Save function:
The Copy button on the bottom right of the front panel is the shortcut for Save
function in the Utility function menu. Pressing this button is equal to the Save
option in the Save menu. The waveform, configure or the display screen could be
saved according to the chosen type in the Save menu.
Save the current screen image:
The screen image can only be stored in USB disk, so you should connect a USB
disk with the instrument.
1. Install the USB disk: Insert the USB disk into the "USB Host port" of "Figure
3- 1 Front panel". If an icon appears on the top right of the screen, the USB
disk is installed successfully. If the USB disk cannot be recognized, format the
USB disk according to the methods in "USB disk Requirements" on P33.
2. After the USB disk is installed, push the Utility button, select Function in the
right menu, select Save in the left menu. In the right menu, select Type as
Image.
3. Select Save in the right menu, an input keyboard used to edit the file name will
pop up. The default name is current system date and time. Turn the M knob to
choose the keys; press the M knob to input the chosen key. The length of file
name is up to 25 characters. Select the
key in the keyboard to confirm.
