48
6. OPERATING ELEMENTS
See fold-out page
1. Display
2. RANGE button (manual measurement range switching)
3. SAVE / SERIES LOG button
4. REL/PC button (REL: reference value measurement button / PC: activates interface)
5. Ÿ/ PASS BEEP button
6. MAX / MIN button (maximum / minimum display switching)
7. COMP / CLEAR button
8. H / LIGHT button (H: hold / LIGHT: light button)
9. Rotary control for selecting the measuring function
10. Adjustable stand
11. Low Imp. 400 kȍ button for switching impedance
12. Ź/ – button
13. LOAD / SETUP button
14. ź / NG BEEP button
15. Ż / + button
16. SHIFT / SLEEP button
17.
Vȍ °CHz measuring jack (with commensurability “Plus”)
18. COM measuring jack (reference potential, “Minus”)
19. mAµA measuring jack
20. 10 A measuring jack
21. DC / AC selection switch
22. Power switch
23. Power inlet (standard C14)
24. USB type B socket
