51
ȍ Ohm (unit of electric impedance)
kȍ Kilo Ohm (= 1000 ȍ)
Mȍ Mega Ohm (= 1000000 ȍ)
nF Nanofarad (unit of electric capacity, = 0.000000001 F)
µF Microfarad (= 0.000001 F)
mF Millifarad (= 0.001 F)
Symbol for capacitance measurement
WARNING! Warning symbol for voltages > 30 V/AC and > 42 V/DC, low impedance function
or measuring leads incorrectly connected
Symbol for data transfer (active interfaces)
Bar graph [only for (V, A, ȍ)]
Symbol for the integrated fuses
Low-pass fi lter for alternate voltage
Auto power off function
9. POWER THE PRODUCT
The product is powered by either six 1.5 V batteries type C or 230 V/AC, 50 Hz. Based on your needs,
select one of the methods below to power the product.
Battery
Disconnect the product from the power source before opening the storage compartment.
Disconnect the measuring leads from the product before opening the storage
compartment.
Never operate the meter when it is open. Danger to life!
A new, fully charged battery must be inserted at initial commissioning or if the battery change symbol
appears on the display.
1. Slide the DC / AC selection switch (21) to the position “DC”.
2. Turn the two screws on top of the product from the position “CLOSE” to “OPEN” to unlock the
storage compartment.
3. Turn the two screws inside from the position “CLOSE” to “OPEN” to unlock the battery compartment.
4. Open the battery compartment and insert / replace six 1.5 V batteries type C while observing the
correct polarity.
