PM100 / 300 USER MANUAL FUNCTION KEYS
VPN 98-052 PAGE 7
SECTION 2 - FUNCTION KEYS
PROG Press and HOLD this key to toggle between default (Red LED off) and stored
settings (Red LED on).
MENU Enter and exit the menu system.
<
Move through menus, select settings etc. Clear erroneous menu data.
>
↵↵ When measuring: acts as a HOLD key (toggle). In the menu system: acts as the
ENTER key.
DISP PM300 only. Selects Channel on Display. Toggles display of Σ quantities and
Neutral Amps.
When in 1ph 2W mode, pressing the [DISP] key sequences through
measurements on all 3 channels. In this mode, all 3 channels are operating
independently of each other and are able to make measurements on different
ranges and at different frequencies.
For waveform display, the [DISP] key sequences through the following
displays:
1/ V & A CH1
2/ V & A CH2
3/ V & A CH3
4/ V CH1, CH2 and CH3
5/ A CH1, CH2 and CH3
6/ V & A CH1, CH2 and CH3
For barchart display, the [DISP] key sequences through the following displays:
1/ V & A CH1
2/ V & A CH2
3/ V & A CH3
