Voltech PM100 User Manual

S
PECIFICATION
PM100 / 300 U
SER
M
ANUAL
P
AGE
26 VPN 98-052
Power
Display Range 0 to 1,999GW
Accuracy
±0.2% rdg ±0.2% rng ±5mW ±0.3%/kHz
Apparent Power
Display Range 0 to 1,999GVA
Accuracy
±0.2% rdg ±0.2% rng ±5mVA ±0.3%/kHz
Reactive Power
Display Range 0 to 1,999GVAr
Accuracy
±0.2% rdg ±0.2% rng ±5mVAr ±0.3%/kHz
Power Factor
Range
0.000 to ±1.000
Accuracy
±0.004 ±0.2% rdg ± 0.2% / kHz
Crest Factor
Range 1.000 to 19.999 (Ranges 2 to 8 only)
Accuracy
± (% pk error + % rms error)
Peak
Voltage and Current
Accuracy
±1%rdg ±1%rng ±0.2%/kHz
(
Ran
g
es 2 to 8 onl
y)
Inrush Current
Range 0-200A
Accuracy
±3.0% rdg ±3.0% rng ±50mA
Frequency
Range 5Hz to 50kHz*
Accuracy 0.2% rdg
*5Hz to 20kHz for the PM300 in three-phase, three-wire and three-phase, and four-wire modes.
