19. Specifications
MODEL
10KW
RATED POWER
10000 W
PV INPUT (DC)
Maximum DC Power
14850 W
Nominal DC Voltage
720 VDC
Maximum DC Voltage
900 VDC
Working DC Voltage Range
300 VDC ~ 900 VDC
Start-up Voltage / Initial Feeding Voltage
320 VDC / 350 VDC
MPP Voltage Range / Full Load MPP
Voltage Range
350 VDC ~ 850 VDC / 400 VDC ~ 800 VDC
Maximum Input Current
2*18.6 A
Isc PV (absolute maximum)
25 A
Max. inverter back feed current to the
array
0 A
GRID OUTPUT (AC)
Nominal Output Voltage
230 VAC (P-N) / 400 VAC (P-P)
Output Voltage Range
184 - 265 VAC per phase
Output Frequency Range
47.5 ~ 51.5 Hz or
59.3~ 60.5Hz
Nominal Output Current
14.5 A per phase
Inrush Current/Duration
17 A per phase / 20ms
Maximum Output Fault Current/Duration
51 A per phase / 1ms
Maximum output Overcurrent Protection
51 A per phase
Power Factor Range
0.9 lead – 0.9 lag
AC INPUT
AC Start-up Voltage
120-140 VAC per phase
Auto Restart Voltage
180 VAC per phase
Acceptable Input Voltage Range
170 - 280 VAC per phase
Nominal Frequency
50 Hz / 60 Hz
AC Input Power
10000VA/10000W
Maximum AC Input Current
40 A
Inrush Input Current
40 A / 1ms
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage
230 VAC (P-N) / 400 VAC (P-P)
Output Frequency
50 Hz / 60 Hz (auto sensing)
Output Waveform
Pure sine wave
Output Power
10000VA/10000W
Efficiency (DC to AC)
91%
BATTERY & CHARGER (Lead-acid/Li-ion)
DC Voltage Range
40 – 60 VDC
Nominal DC Voltage
48 VDC
Maximum Battery Discharging Current
275 A
Maximum Charging Current
200 A
