Technical Data
Engines
Engine model D11-670
Crankshaft power* @ 2300 rpm 493 kW (670 hp)
Max. torque @ 1500 rpm 2527 Nm (1864 lbf.ft)
After market designation D11A-B
No. of cylinders and configuration in-line 6
Bore 123 mm (4.84”)
Stroke 152 mm (5.98”)
Displacement
10.8 dm
3
(659 in
3
)
Dry weight bobtail 1130 kg (2491 lb)
Compression ratio 16.5:1
Low idle speed** 600 (±25) rpm.
* According to ISO 8665.
** At delivery, the idling speed is adjusted to 600 rpm. If needed, the speed can be adjusted within the range
550-700 rpm.
96 7748887 04-2008
