MD2030-C & MS2A
3
4
4
7
8 12
9
MD2030-C & MS2A
10 11
Presentation
17
16
15
2
3
MD2040-C & MS2L
MD2040-C & MS2L
1.
Cap for replenishing of refrigerant
14.
I
njection pump
2.
Expansion tank
15.
Oil filter
3.
Relay box with fuses
16.
Feed pump (with hand pump)
4.
Flexible suspension
17.
Oil cooler, reverse gear
5.
Starter motor
1
8.
Folding propeller
6.
Alternator
1
9.
Refrigerant intake, S-drive
7.
Oil dipstick, reverse gear/S-drive
20.
Refrigerant cock (sea water), S-drive
8.
Cap for oil dipstick, reverse gear/S-drive
21.
Oil drain, S-drive
9.
Fuel filter
22.
Zinc anode (zinc ring)*
1
0.
Cap for oil replenishment, engine
11.
Oil dipstick, engine
Note:
When running in freshwater the magnesium anode
12.
Air filter/Air intake
(
magnesium ring) should be used.
1
3.
Sea water pump
