33
WWW.VORONDESIGN.COM
INSTALL FRONT
(4) M3x6 BHCS
+
(4) M3 Washers
DON’T FORGET THESE WASHERS!
Without them, there is a possibility the carriage won’t be tight. Make sure these are tight.
IF YOU HAVE BELT EXCESS, TUCK.
This should be a loose tuck, leave enough of a loop that the mechanism can move.
It’s just meant to keep the belt out of the way. On both sides, of course.
