IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 96 -
P14.06
Speed limit value setting
-100.0%～100.0%
100.0%
☆
P14.07
Reverse speed limit
Relative to maximum frequency：0.0%～100.0%
Notice:Speed limit for reverse speed direction
not specified by the speed limit source
40.0%
☆
P14.08
Torque setting over limit
speed
0: Symmetrical torque command
After the motor speed exceeds the speed limit
value, the torque input source sets the absolute
value of the torque reference, and the direction
of the torque is always the braking force.
1: Enter speed mode
After the motor speed exceeds the speed limit
value, enter the speed mode, and the inverter
will limit the speed to within the speed limit value
as much as possible.
0
★
P14.10
Static friction torque
0.0%～50.0%
10.0%
☆
P14.11
Static friction torque
compensation
0.00Hz～50.00Hz
It is used to overcome the static friction force at
the start, and the speed is higher than P14.11
and the static friction torque compensation is
cancelled.
1.00Hz
★
P14.12
Dynamic friction factor
0.0%～50.0%
Dynamic friction at rated speed
Notice: motor sliding friction torque at rated
rotating speed
0.0%
☆
P14.13
Dynamic friction starting
value
0.0%～50.0%
0.0%
☆
r14.14
Torque mode current
speed limit value (forward)
Display the current forward speed limit value,
unit: 0.01Hz
-
●
r14.15
Torque mode current
speed limit value (reverse)
Display the current reverse speed limit value,
unit: 0.01Hz
-
●
16 Group Energy saving control
r16.00
Electricity meter count
(32BIT)
Unit:KW/H
-
●
