- 49-
Functio
n code
Parameter name
Description
Default
Property
P01.12
Jump frequency start up
protection
Unit/ten/hundred’digit：three jump frequency
1/2/3
0：Disable
1：Enable (avoid risk speed)
000
☆
P01.13
Jump frequency 1 lower
limit
0.00Hz～(P01.14)
0.00Hz
☆
P01.14
Jump frequency upper
limit
P01.13- (P01.06)Maximum frequency
0.00Hz
☆
P01.15
Jump frequency 2 lower
limit
0.00Hz～(P01.16)
0.00Hz
☆
P01.16
Jump frequency 2 upper
limit
P01.15～maximum frequency(P01.06)
0.00Hz
☆
P01.17
Jump frequency 3 lower
limit
0.00Hz～(P01.18)
0.00Hz
☆
P01.18
Jump frequency 3 upper
limit
P01.17～maximum frequency(P01.06)
0.00Hz
☆
Risk speed or Jump frequency start up protection is used to some situation which need avoid motor speed and
speed range,for example,due to mechanical resonance ,P01.12 will be enabled to avoide risk speed in forward or
reverse mode
。
