Vorwerk Kobold System VK 140 - Kobold VK 140 with EB 360 Maintenance; Changing the Filter Bag

VK 140
43
VK 140
42
Inserting new filter bags
Press the Dovina fragrance chip into the
new filter bag plastic plate.
(FIGURE 23)
 Small parts, like the Dovina fragrance
chips, must be kept out of children’s reach.
Insert the filter bag plastic plate starting
with the bottom first, ensuring the two
small plastic “tabs” go over the green base
plate of the Kobold VK 140.
(FIGURE 24)
Then press the top of the filter bag plastic
plate into the metal clasp until you hear a
click.
(FIGURES 25 AND 26)
FIGURE 23
FIGURE 24
FIGURE 25
FIGURE 26
Maintenance Maintenance
Changing the filter bag
and inserting the Dovina
fragrance chip
Press the yellow release button.
(FIGURE 19)
Open the front filter cassette.
(FIGURE 20)
Remove the bag by grasping the ring, first
pushing forward…
(FIGURE 21)
… and then pulling outward.
(FIGURE 22)
Then dispose of the full bag properly.
FIGURE 19
FIGURE 20
FIGURE 21
FIGURE 22
click
click
