TSLM - M601 Operational & Install Manual
Electrical & Mechanical Specifications
Power Requirements 10 to 32 VDC
Supply Current (start or run sequence) < 10 A
Supply Current (monitoring only) 50 mA
Operating Temperature -40°C to +85°C
Storage Temperature -55°C to +125°C
Dimensions (SN 7001 and later)
Weight 180g (0.4 lb)
Dimensions 100 x 75 x 25mm (3.94" x 2.95" x 0.98")
06/29/16 © 2016 VR Avionics page 11 of 33
