TSLM - M601 Operational & Install Manual
Installation
Tools and Equipment
Tools and equipment required for installation (not included in the purchase) are:
✔ Wire cutters
✔ Wire strippers
✔ Wire (single core, Teflon insulated 20 AWG)
✔ Thermocouple wire (K-type)
✔ Connector crimp tool
✔ DB-25 female connector with crimp pins
✔ Personal computer running Windows 98 or higher, with a spare serial port. If no serial port,
a USB port together with a USB-to-Serial adapter will do.
✔ Standard RS-232 cable (DB-9 male to DB-9 female)
✔ Torque and Oil Pressure transducers (see page 23)
Description Part Numbers
Crimp contacts M24308/10-1 M39029/63-368 AMP 205090-1
Crimp tool M22520/2-01 AFM8 (DMC)
Crimp tool positioner M22520/2-08 K13-1 (DMC)
Insertion tool MS1969/1-02 DAK 145
Extraction tool MS1969/1-02 DAK 145
06/29/16 © 2016 VR Avionics page 13 of 33
