52
(3)
(2)
(1)
(1)
1 2
6. Tables with winding handle for height adjustment
Seat/seat adjustment: 65 - 85 cm 3 mm per handle turn
Seat/seat adjustment: 65 - 85 cm 12 mm per handle turn
Seat/standing adjustment: 65 - 125 cm 40 mm per handle turn
To adjust the height [Figure 1] , rotate the winding handle (1); clock-
wise for up - anticlockwise for down.
The manual winding handle (1) is locked in the park position (2) below
the table top [Figure 2]. To adjust the height, release the handle from
its locked position and pull it forwards until it engages in its operating
position (3) [Figure 2].
Caution! After the table height has been adjusted, the manual
winding handle must be locked in the park position again.
