59
9. Technical data
Name C-type/T-type foot
The height depends on the
choice of variant: from 65 to 125 cm
Maximum lifting load at 75 kg (full surface area)
Operating time 2 minutes “ON” and
18 minutes “OFF”
safety shut-o
Ambient temperature must not be below +0°C
for operation and must not exceed + 35 °C
Safety range End position approx. 11 cm above
lowest table height
Sound emissions < 50 dB(A)
Travel speed 38 ± 2 mm/sec
Relative humidity 5 to 85
Power supply 230 V
Power consumption 300 W when operating with a load
Protection type, IP class IPX0
Protection class II
Frequency range 50 Hz
Standby power, primary (typical) 0.1 W
