10 Maintenance
100_0302_mt_0001.fm 32
10.4.4 Lubricating the machine
1. Remove any dirt around the zerk fitting.
2. Place filled manual grease gun onto the zerk fitting and operate approx. 20 times.
3. Wipe the area around the zerk fitting with a clean cloth.
10.4.5 Checking/cleaning/replacing spark plug
Performing preparations
1. Switch off the engine.
2. Let machine cool off.
Removing the spark plug
1. Clean around the spark plug thoroughly.
2. Pull off the spark plug cap from the spark plug.
3. Loosen and unscrew the spark plug with a spark plug wrench.
Item Designation
1 Zerk fitting
NOTICE
Only use special lubricants for lubricating, see chapter Technical Data.
CAUTION
Touching a hot spark plug can cause burns.
Only remove the spark plug when the engine has cooled down.
NOTICE
Do not pull the spark plug cap off the spark plug by the ignition cable.
