Transportation
Lashing the machine 6.4
27
[en] | 07/2022 | 5100056271 | BS-2 | Operator’s Manual
NOTICE
Note on the lifting procedure!
► Designate a competent instructor for a safe lifting procedure.
1. Attach suitable sling to central suspension 1.
2. Load the machine into or onto the transport vehicle.
3. Transfer the machine to the front onto the transport roller 2.
6.4 Lashing the machine
1. Lash the machine to the transport vehicle as shown.
2. Attach the tension belts 1 over the machine and tighten them.
ð The machine is secured against unrolling, slipping and tipping over.
6
