Wacker Neuson BS-2 User Manual

Technical Data
Combustion engine 13.4
51
[en] | 07/2022 | 5100056271 | BS-2 | Operator’s Manual
Type BS60-2 11" BS60-2plus 11"
Material number machine 5100051580 5100030604
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS70-2 11" BS70-2plus 11"
Material number machine 5100030607 5100030609
Material number engine 5100008899 5100009016
Number of strokes [1/min] 687 687
Impact force [kN] 20 20
Forward travel [m/min] 8,9 8,9
Length [mm] 673 687
Width [mm] 343 343
Height [mm] 965 965
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 280
Operating weight [kg] 74 74
Rated ouput [kW] 2 2
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,9 0,9
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 93 93
Sound power level LWa measured [dB(A)] 105 105
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 6,9 7,0
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,8 0,6
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
13.4 Combustion engine
Engine manufacturer Wacker Neuson
Material number engine 5100008899
Engine type WM80
Combustion processes two-stroke
Cooling Air
Cylinder 1
Cubic capacity [cm3] 80
Fuel type Oil/gasoline mixture; oil/alkylate gasoline mixture
Fuel type Oil/gasoline mixture
Fuel mixing ratio 1:50
