Wacker Neuson BS-2 User Manual

Technical Data
13.3 BS
50
Operator’s Manual | BS-2 | 5100056271 | 07/2022 | [en]
Type BS60-2 11" BS60-2 11"
Material number machine 5100037561 5100030600
Operating weight [kg] 66 66
Rated ouput [kW] 1,9 1,9
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,9 0,9
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 94 94
Sound power level LWa measured [dB(A)] 105 105
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 9,7 9,7
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,7 1,7
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS60-2 11" BS60-2plus 11"
Material number machine 5100051580 5100030604
Material number engine 5100008899 5100009016
Number of strokes [1/min] 687 687
Impact force [kN] 18 18
Forward travel [m/min] 9,8 9,8
Length [mm] 673 673
Width [mm] 343 343
Height [mm] 965 965
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 280
Operating weight [kg] 66 66
Rated ouput [kW] 1,9 1,9
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,9 0,9
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 94 94
Sound power level LWa measured [dB(A)] 105 105
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 9,7 8,7
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,7 0,6
