Technical Data
BS 13.3
49
[en] | 07/2022 | 5100056271 | BS-2 | Operator’s Manual
Type BS50-2 11" BS50-2 6"
Material number machine 5100030591 5100030592
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,7 0,6
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS50-2plus 11" BS50-2plus 6" (24mm)
Material number machine 5100030596 5100030597
Material number engine 5100009016 5100009016
Number of strokes [1/min] 687 687
Impact force [kN] 16 16
Forward travel [m/min] 9,5 7,9
Length [mm] 673 673
Width [mm] 343 343
Height [mm] 940 940
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 165
Operating weight [kg] 59 56
Rated ouput [kW] 1,8 1,8
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,7 0,7
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 93 92
Sound power level LWa measured [dB(A)] 106 104
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 8,9 6,5
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,3 0,6
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS60-2 11" BS60-2 11"
Material number machine 5100037561 5100030600
Material number engine 5100008899 5100008899
Number of strokes [1/min] 687 687
Impact force [kN] 18 18
Forward travel [m/min] 9,8 9,8
Length [mm] 673 673
Width [mm] 343 343
Height [mm] 965 965
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 280
