Wacker Neuson BS-2 User Manual

Technical Data
13.3 BS
48
Operator’s Manual | BS-2 | 5100056271 | 07/2022 | [en]
Type BS50-2 10" BS50-2 11"
Material number machine 5100058346 5100068309
Width (Ramming shoe) [mm] 250 280
Operating weight [kg] 61,6 59
Rated ouput [kW] 1,8 1,8
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,7 0,7
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 93 93
Sound power level LWa measured [dB(A)] 106 106
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 11,1 11,1
Measurement uncertainty of the total vibration value
ahv [m/s2]
1,7 1,7
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
Type BS50-2 11" BS50-2 6"
Material number machine 5100030591 5100030592
Material number engine 5100008899 5100008899
Number of strokes [1/min] 687 687
Impact force [kN] 16 16
Forward travel [m/min] 9,5 7,9
Length [mm] 673 673
Width [mm] 343 343
Height [mm] 940 940
Length (Ramming shoe) [mm] 340 340
Width (Ramming shoe) [mm] 280 165
Operating weight [kg] 59 56
Rated ouput [kW] 1,8 1,8
Rated speed [1/min] 4400 4400
Standard ISO 3046-1 ISO 3046-1
Engine type WM80 WM80
Oil specifications (Ramming system) SAE 10W-40 SAE 10W-40
Oil volume (Ramming system) [l] 0,7 0,7
Operating temperature range [°C] -10 – +40 -10 – +40
Storage temperature range [°C] -30 – +50 -30 – +50
Sound pressure level LpA [dB(A)] 93 92
Sound power level LWa measured [dB(A)] 106 104
Sound power level LWa guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 11,1 6,5
