Maintenance
Maintenance work 9.3
37
[en] | 07/2022 | 5100056271 | BS-2 | Operator’s Manual
1. Remove air filter lid1.
2. Remove air filter element 2 and separate filter elements.
ð Pre-filter 3 and foam filter insert 4.
3. Check both air filter elements for cracks and holes, replace if dam-
aged.
Cleaning the air filter insert
1. Knock out air filter insert on a hard surface.
2. Blow with compressed air from the inside through the filter insert.
Cleaning the foam filter insert
1. Wash out foam filter insert in soapy water.
2. Rinse thoroughly with warm water.
3. Rinse with clean water.
4. Leave to dry.
Cleaning the filter housing
1. Wipe out filter housing 4 with a cloth.
2. Do not use compressed air!
3. Clean the dirt discharge slot of the pre-filter.
4. Insert both filter elements into the filter housing.
5. Screw on air filter cover.
9.3.6 Checking and refilling the oil level in the tamping system
NOTICE
Damage to machine due to incorrect oil level!
A too high oil level can result in a hydraulic lock in the ramming system.
This can lead to faulty operation and damage to the ramming system.
► Do not overfill the ramming system with oil.
9
