Wacker Neuson BS 60-4 Repair Manual

Engine and Upper Machine Components Repair
30 wc_tx001546gb.fm
4.3 Replacing the Throttle Control (2010 4-stroke models)
Requirements
• Machine shut down and cool
• Torque wrench
Removal
Perform the procedure below to remove the throttle control.
4.3.1 Remove the silencing cover. See topic Removing the Silencing Cover.
4.3.2 Disconnect the throttle cable at the swivel (a) and the clamp (b).
4.3.3 Remove the clamp
(c).
4.3.4 Clip the wire ties (d).
4.3.5 Remove the bolt
(h) and hardware (b).

Wacker Neuson BS 60-4 Specifications

General

Engine Manufacturer	Honda
Displacement	163 cm³
Operating Weight	66 kg
Percussion Rate	700 blows/min
Engine	Honda GX 160
Stroke	60 mm
Engine Type	4-stroke
Fuel Tank Capacity	3.0 liters
