Wacker Neuson BS 60-4 Repair Manual

Engine and Upper Machine Components Repair
68 wc_tx001546gb.fm
4.21 Removing Walbro Carburetor (standard choke models)
4.21.1 Stop the machine and allow it to cool.
4.21.2 Place the throttle in the OFF position.
4.21.3 Disconnect the ignition wire (a) from the spark plug.
4.21.4 Remove the carburetor guard
(b).
4.21.5 Loosen the hose clamp
(c) and remove the air duct (d).
4.21.6 Remove the two screws and remove the flange
(e) and the carburetor
from the machine.
4.21.7 Remove the screws (f) and remove the adapter (g).
4.21.8 Disconnect the throttle cable
(h). Remove the spring (i).

Wacker Neuson BS 60-4 Specifications

General

Engine Manufacturer	Honda
Displacement	163 cm³
Operating Weight	66 kg
Percussion Rate	700 blows/min
Engine	Honda GX 160
Stroke	60 mm
Engine Type	4-stroke
Fuel Tank Capacity	3.0 liters
