Wacker Neuson BS 60-4 Repair Manual

Engine and Upper Machine Components Repair
66 wc_tx001546gb.fm
4.20 Replacing the WM 80 Engine (2010 and later models)
Requirements
• Engine cool
• Carburetor removed
Removal
Perform the procedure below to remove the engine.
4.20.1 Remove the carburetor. See topic Removing the Carburetor.
4.20.2 Remove the muffler (a).
4.20.3 Remove the bracket
(b).
4.20.4 Disconnect the wiring to the switches (c).
4.20.5 Remove the screws that hold the engine and remove the engine
(d)
from the machine.
Result
The engine has now been removed.

Wacker Neuson BS 60-4 Specifications

General

Engine Manufacturer	Honda
Displacement	163 cm³
Operating Weight	66 kg
Percussion Rate	700 blows/min
Engine	Honda GX 160
Stroke	60 mm
Engine Type	4-stroke
Fuel Tank Capacity	3.0 liters
